SH150i

Description

Fitur Terbaru

Mesin
tipe mesin Liquid Cooled, 4stroke, SOHC, eSP
kapasitas mesin 153 cm3
sistem suplai bahan bakar PGM-FI (Programmed Fuel Injection System)
diameter x langkah 58 x 57.9 mm
tipe transmisi Automatic
rasio kompresi 10,6:1
daya maksimum 10.9 kW/8,250rpm
torsi maksimum 13,9 Nm/6,500rpm
tipe starter Electric
tipe kopling Automatic Centrifugal, Dry
Rangka & kaki-kaki
tipe rangka Steel, under born type
tipe suspensi depan 33 mm telescopic fork, 89 mm axle travel
tipe suspensi belakang Dual damper unit swing arm, 83 mm axle travel with 5-step preload adjusment
ukuran ban depan 100/80–16 M/C 50P ( Tubeless ) U-section 10 spoke cast aluminum
ukuran ban belakang 120/80–16 M/C 60P ( Tubeless ) U-section 10 spoke cast aluminum
rem depan Disc Brake, 2 Piston Calipers, 240 mm Disc
rem belakang Disc Brake, 1 Piston Calipers, 240 mm Disc
Sistem Pengereman Antilock Braking System 2 Channel
Dimensi & berat
panjang x lebar x tinggi 2,026 x 740 x 1,158 mm (LxWxH)
jarak sumbu roda 1,340 mm
jarak terendah ke tanah 146 mm
curb weight 136 kg (ABS)
Radius Putar 26°
Tinggi Tempat Duduk 799 mm
Kapasitas
kapasitas minyak pelumas 0.9 liter
kapasitas tangki bahan bakar 7.5 liters
Kelistrikan
tipe baterai atau aki 12V/5AH, ACG Output 343W
sistem pengapian Digital transistorized with electronic advance, 12° BTDC (idle) ~ 65° BTDC (8,500min1)
tipe busi CPR7EA9(NGK)
Lampu Depan LED
