Download Katalog Part

Lihat Pricelist

Description
Product Specifications

Description

PRODUCT FEATURE

Mesin

tipe mesin	Air-Cooled, 4-Stroke, SOHC Single Cylinder
kapasitas mesin	124,89cc
sistem suplai bahan bakar	PGM-FI (Programmed Fuel Injection System)
diameter x langkah	52,4 x 57,9 mm
tipe transmisi	Manual, 4-speed
rasio kompresi	9,3 : 1
daya maksimum	6,5 Kw / 7.000 rpm
torsi maksimum	11 Nm / 4.500 rpm
tipe starter	Electric & Kick
tipe kopling	Wet, Multi-plate Coil Spring

Rangka & kaki-kaki

tipe rangka	Backbone, Steel
tipe suspensi depan	Telescopic Suspension
tipe suspensi belakang	Twin Rear Suspension
ukuran ban depan	80/90-17M/C 44P
ukuran ban belakang	80/90-17M/C 50P
rem depan	220mm Hydraulic Disc
rem belakang	190mm Hydraulic Disc
Sistem Pengereman	ABS 1 Channel

Dimensi & berat

panjang x lebar x tinggi	1.960 x 805 x 1.085 mm
jarak sumbu roda	1.255 mm
jarak terendah ke tanah	165 mm
curb weight	120 kg
Tinggi Tempat Duduk	800 mm

Kapasitas

kapasitas minyak pelumas	0,7 L
kapasitas tangki bahan bakar	5,3 L

Kelistrikan

sistem pengapian	Full-Transisterized
tipe busi	NGK CPR6EA-9 / DENSO U20EPR9
Lampu Depan	Hi 10,1 W x 1 LED - Low 5,1 W x 1 LED
