Description
COLOR VARIANT
PRODUCT FEATURE
Mesin
| tipe mesin | Liquid-Cooled, 4-Stroke, 16-Valve, DOHC, Inline 4-cylinder |
| kapasitas mesin | 1000 cc |
| sistem suplai bahan bakar | PGM-DSFI |
| diameter x langkah | 76 x 55.1 mm |
| tipe transmisi | 6-Speed with Quickshifter |
| rasio kompresi | 13 : 1 |
| daya maksimum | 141 kW/13,000 rpm |
| torsi maksimum | 116 Nm/11,000 rpm |
| tipe starter | Electric |
| tipe kopling | Wet, Multiplate with Diaphragm Spring with Assist Slipper |
Rangka & kaki-kaki
| tipe rangka | Steel Diamond; Aluminum Composite with Twin Spar |
| tipe suspensi depan | Telescopic Inverted Fork with An Inner Tube Diameter of 43 mm, and NIX30 Smart-EC (OHLINS) Front Fork with Preload, Compression and Rebound Adjustments, 120 mm stroke. |
| tipe suspensi belakang | Unit Pro-Link with Gas-Charged TTX36 Smart-EC (OHLINS) Damper Featuring Preload and Compression and Rebound Damping Adjustment, 60 mm Stroke. |
| ukuran ban depan | 120/70ZR-17M/C (58w) |
| ukuran ban belakang | 190/50ZR-17M/C (73w) |
| rem depan | Brembo Double Disc 320 mm |
| rem belakang | Single Disc 220 mm |
Dimensi & berat
| panjang x lebar x tinggi | L x W x H) 2,065 x 720 x 1,125 mm |
| jarak sumbu roda | 1,405 mm |
| jarak terendah ke tanah | 129 mm |
| curb weight | 195 kg |
| Tinggi Tempat Duduk | 834 mm |
Kapasitas
| kapasitas minyak pelumas | 3.4 l |
Kelistrikan
| tipe baterai atau aki | 12 V-4.5 Ah (Li-ion) |
| Lampu Depan | LED |
